  • High Quality TH504 Tractor with CE (50HP, 4WD) 2WD Hot Sale New Design MADE IN CHINA
  • High Quality TH504 Tractor with CE (50HP, 4WD) 2WD Hot Sale New Design MADE IN CHINA
High Quality TH504 Tractor with CE (50HP, 4WD) 2WD Hot Sale New Design MADE IN CHINA High Quality TH504 Tractor with CE (50HP, 4WD) 2WD Hot Sale New Design MADE IN CHINA

High Quality TH504 Tractor with CE (50HP, 4WD) 2WD Hot Sale New Design MADE IN CHINA

 High Quality TH504 Tractor with CE (50HP, 4WD) 2WD Hot Sale New Design MADE IN CHINA

TH504 tractor(50HP,4WD)  power steeing.

Model TH504
Type 4 X 4 Wheeled Type
General Specifications

Driving mode 4WD
Overall Dimensions (mm) W X D X H 3600X1620X2120
Tractor Dry Mass (kg) 2300
Rated Tractive Force (N) 13000
Max. tractive power (kw) ≥27.5
Wheel Base (mm) 1960
Front Wheel Tread (mm) 1280-1300 Adjustable
Rear Wheel Tread (mm) 1300-1500 Adjustable
Front Wheel Tire 8.30-20
Rear Wheel Tire 12.4-28
Min. Turning Radius (m)

With oneside braking 4.0±0.2
No braking 4.6±0.2
Min. Ground Clearance (mm) 396
Transmission Box & Steering System

Transmission Box Spur gear, plane compound
Gear Shifts (4+1)X2
Theoretical Speed (km/h) 1.96-27.21
Clutch single stage, single plate, dry friction, constant contact
Steering System  power steering
Working Devices

Hydraulic System half-seperated
Lifter Tillage Depth Control Method Draft and Position Control
Max. Lifting Capacity (N) ≥8280
Safety Valve Pressure (Mpa)

Three Point Hitch System I35, Post Positioned,Category
PTO Type Post Positioned, Non-independent
Max. PTO Power (kw) 33
PTO Rev. (rpm) 540/720, 540/1000 or 720/1000
Engine

Type Vertical type, four-cylinder diesel engine
Model JD4100
Bore X Stroke (mm) 100X105
Rated Power (kw) 36.8
Rated Revolution (rpm) 2400
Max. Torque (N.m)

Rev. at Max torque (rpm)

Lubricating Method Pressure splash lubrication
Cooling Method  Forced Water Circulation
Fuel consumption (g/kw.h) ≤243
Engine Oil Consumption (g/kw.h) ≤2.0
